Product category: backhoe loader
Name: BL105-25H side shift version backhoe loaders
Product brief description:
BL105-25H Side shift version backhoe loaders
-- Different engines
National II economic version of Weichai, Yuchai, Cummins engines; Euro V emission standard Yuchai engines; EPA emission standard Cummins engines, etc.
-- Strong power
Adopting reliable hydraulic system technology to ensure smooth and efficient operation, which can meet more auxiliary equipment configuration requirements.
-- ROPS/FOPS cab
Prevent rollover and falling object damage and ensure your safety during operation.
-- Multifunctional attachments
Meet different working needs, it enhances the flexibility and versatility.
-- Lower shipping cost
3 sets BL105-25H can be loaded into 2*40HQ container.
A: 2500mm B:3080mm C:2350mm D:2030mm E:2285mm F:4611mm
G: 3907mm H:3120mm I:870mm J:37° K:5370mm L:3725mm
M:3510mm N1:5210mm N2:5565mm Z:6420mm
| Model | BL105-25H ( side shift version) |
| Rated load(kg) | 2500 |
| Bucket capacity (m³) | 1.2 |
| Overall Weight(kg) | 10200 |
| Max. Dumping height(mm) | 3120 |
| Dumping distance(mm) | 870 |
| Gearbox model | 315Y |
| Transmission mode | Hydraulic torque converter |
| Low gear(km/h) | 5 |
| High gear(km/h) | 35 |
| Max. steering angle | 土 18° |
| Length(mm) | 6400 |
| Width(mm) | 2500 |
| Height(mm) | 3080 |
| Bucket width(mm) | 2460 |
| Wheel base(mm) | 2350 |
| Wheel thread(mm) | 2030 |
| Min. ground clearance(mm) | 380 |
| Engine model | 4105 turbo |
| Engine brand | Weichai |
| Rated power(kw) | 70 |
| Rated speed(r/min) | 2200 |
| Alxe model | ZL30 steering axle |
| Tyre | 16.9-28 |
| Working break | air push oil |
| Parking break | Handbrake clamp disc type |
| Turning raduis(outside of bucket) (mm) | 6420 |
| Backhoe bucket capacity(m³) | 0.3 |
| Max. digging depth(mm) | 3510 |
| Max. digging radius(mm) | 5565 |
| Max. dumping height(mm) | 3725 |
| Max. digging height(mm) | 5370 |
| Max.digging radius lifting capacity(kg) | 1220 |
