Product category: Forklift loader
Name: FL40 diesel forklift loader
FL40 Diesel Forklift Loader
——Unmatched Power & Efficiency
High-performance diesel engine: YUNNEI YC4A90-T22 delivers 66kW at 2300rpm for heavy-duty operations.
——True Off-Road Capability
Heavy-duty drivetrain: Big hub reduction axle delivers exceptional torque for slopes and rough terrain.Superior clearance: 200mm ground clearance with 16/70-20 all-terrain tires conquers obstacles.
——Engineered for Heavy Lifting
4000kg rated capacity with 4000mm lift height for demanding material handling，Stable platform: 2600mm wheelbase and 1685mm wheel track ensure load stability.
——Built for Reliability
Dual braking system: Air-over-hydraulic service brake + disc parking brake，Durable construction: Reinforced frame and components for longevity.
—2 sets in 1*40HQ container
| Rated Load | 4000 |
| Operating weight | 6315 |
| Dimension L*W*H(mm) | 6350x2080x2880 |
| Fork length(mm) | 1520 |
| Lift height(mm) | 4000 |
| Gate frame inclination front/back (°) | Front 6 / Back 12 |
| Wheel base(mm) | 2600 |
| Wheel thread(mm) | 1685 |
| Min. ground clearance(mm) | 200 |
| Max.steering angle(°) | ±35° |
| Engine model | YC4A90-T22 |
| Engine brand | YUNNEI |
| Rated power(kw) | 76 |
| Rated speed(r/min) | 2300 |
| Gearbox model | 280F |
| Transmission mode | Hydraulic torque converter |
| Low gear(km/h) | 6 |
| High gear(km/h) | 20 |
| Alxe model | big hub reduction axle |
| Tyre | 16/70-20 |
| Working brake | air push oil |
| Parking brake | handbrake clamp disc type |
